Wavenet AC1402RBK4-500 14AWG, 2 Conductors (105), Direct Burial Audio Cable, Black 500' Reelex II

Wavenet AC1402RBK4-500 14AWG, 2 Conductors (105), Direct Burial Audio Cable, Black 500' Reelex II
Availability:
Out of stock
SKU WAV-AC1402RBK4-500
Sold out

Wavenet AC1402RBK4-500 14AWG, 2 Conductors (105), Direct Burial Audio Cable, Black 500' Reelex II

  • Ideal for high-end commercial or residential in-wall rated audio (speaker) installations
  • 14 AWG with 2 insulated conductors made with Stranded Oxygen Free Copper
  • Sequential footage marking

Standards

  • c(ETL) Listed CMR/CMP
  • TIA-568-C.2
  • RoHS Compliant

Specifications

  • Number of Conductor - 2
  • AWG - 14
  • Stranding - 105
  • Diameter - 0.0063 (inches)
  • Insulation Material - PVC
  • Diameter - 0.1023 (inches)
  • Average Thickness - 0.014 (inches)
  • Min. Point Thickness - 0.013 (inches)
  • Assembly Diameter - 0.2047 (inches)
  • Jacket Material - PVC
  • Outer Diameter - 0.2519 (inches)
  • Average Thickness - 0.0236 (inches)
  • Min. Point Thickness - 0.02126 (inches)
  • Rip Cord - Nylon
  • Conductor Resistance - 9.2 (ohms)
  • Nominal Weight - 22 (pounds)
  • Voltage Rating - 300V (volts)
