Panamax BATT1500-EXT Battery Extension Pack for F1500-UPS and MB1500

Availability:
Out of stock
SKU PAN-BATT1500-EXT
Sold out
Panamax BATT1500-EXT External Battery Extension Pack for F1500-UPS and MB1500

Brand:
Panamax
MPN: BATT1500-EXT
Condition: New

The PFPower external battery pack (BATT1500-EXT) is designed for variety of Panamax and Furman UPS systems.
When combined with the UPS, the battery pack provides extended runtime with a 48V DC external connection.

Form Factor - 2U configuration supports both rack and tower mounting.
Metal Housing - Rigid metal construction allows for placement in areas with a demanding environment.
Power On/Off Switch - Local power switch for manual reset & control.
Back-panel fuse - User replaceable fuse which is easily accessed from the rear panel.
Compatible with Furman F1500-UPS and Panamax MB1500.

AC Power
Voltage:
48V
Physical
Dimensions:
2U Rack, 17" x 19" x 3.5"
Weight: 70lbs
Battery
Sealed Maintenance Free Lead Acid Battery:
12V/9.0AHx8
Interface: PP75
Environmental
Operating Temperature:
32F to 104F (0C to 40C)
Operating Relative Humidity: 0 to 95%
Safety Approvals
Certifications:
FCC Class B certified, cUL, UL1778
RoHS: RoHS Compliant
Warranty: 2 year warranty

Two adjustible length rack mounting rails and hardware
Two front mounting ears
One user's manual basic operation guide
