Orion CBW804S Cobalt Series Bass 8" Single Voice Coil 4 Ohm 800 Watts Max Car Subwoofer (Each)

Availability:
Low stock
SKU ORI-CBW804S

Orion CBW804S Cobalt Series Bass 8" Single Voice Coil 4 Ohm 800 Watts Max Car Subwoofer (Each)

Upgrade your sound system with the Orion CBW804S 8 inch car subwoofer. This model is designed for clean bass and dependable performance. It works well in daily driving setups and budget-friendly upgrades.

With 200W RMS and 800W max power, the CBW804S delivers tight low-end response. It stays controlled, even at higher volume levels. In addition, the single 4-ohm voice coil makes amplifier pairing simple and efficient.

The subwoofer uses a UV-coated paper and fiber blend cone. As a result, bass remains accurate and consistent over time. A high-quality foam surround supports smooth cone movement and long-term durability.

Moreover, the 2-inch copper voice coil on a Kapton former improves heat dissipation. This design helps the subwoofer perform reliably during extended listening sessions. With a 3.78-inch mounting depth, it fits easily into sealed or ported enclosures.

Whether you are replacing a factory subwoofer or building a new system, the Orion CBW804S delivers solid bass backed by trusted Orion engineering.

  • 8 inch car subwoofer for daily use
  • 200W RMS / 800W max power handling
  • Single 4-ohm voice coil for easy wiring
  • UV-coated paper and fiber blend cone
  • High-quality foam surround for durability
  • 2-inch copper voice coil on Kapton former
  • Compact 3.78-inch mounting depth

Specifications

  • Subwoofer Size: 8 (Inches)
  • Voice Coil Configuration: Single 4-ohm
  • Power Handling (Peak): 800 Watts
  • Power Handling (RMS): 200 Watts
  • Sensitivity: 86 dB
  • Frequency Response: 20 Hz - 300 Hz
  • Voice Coil Diameter: 2 (Inches)
  • Cone Material: UV Coated Paper / Fiber Blend Cone
  • Surround Material: Foam Surround
  • Magnet Information: 40 Oz Ferrite
  • Overall Depth: 113.25mm / 4.46 (Inches)
  • Mounting Depth: 96mm / 3.78 (Inches)
  • Overall Diameter: 214mm / 8.43 (Inches)
  • Mounting Diameter: 204mm / 8.03 (Inches)
