16-Channel 12MP NVR 8 PoE Ports 1X SATA Network Video Recorder with AI Management Function

16-Channel 12MP NVR 8 PoE Ports 1X SATA Network Video Recorder with AI Management Function
Availability:
Low stock
SKU CST-NR-5116N-P8

NR-5116N-P8 16-Channel 12MP NVR 8 PoE Ports 1xSATA Network Video Recorder with AI Management Function (No HDD included)

8-Channel PoE ports and supports up to 8-Channel additional via PoE switch. 12MP NVR, 120Mbps, 16CH input max, 1 x SATA, 9x RJ-45, Audio I/O 1/1, Plug & Play with AI Management Function

Docs/Instruction Links

Specifications

System

  • Main Processor  -  Dual Cortex A53
  • Operating System   - Embedded LINUX

Video

  • Input  -  16CH(12MP/8MP/6MP/5MP/4MP/3MP/1080p/1280×1024/960p/720p/D1/CIF)
  • Output   - 1*HD,1*VGA

Audio

  • Input  -  1 Port RCA, support 16CH IPC audio input
  • Output   - 1 Port RCA(Linear, 1kΩ), HD output
  • Audio Bit Rate  -  64kbps
  • Audio Compression standard   - G711U, G711A
  • Intercom -   support (two-way)

Alarm

  • Sensor Input  -  N/A
  • Output  -  N/A
  • Motion Detection   - 16 Channel, MD Zones: 396 (22 × 18)
  • Trigger Events  -  Recording, Email, FTP, Snapshot and Screen Tips

Display

  • HD Output1  -  4K(3840*2160)/2K(2560*1440)/1920*1080/1280*1024/1280*720/1024*768
  • HD Output2  -  N/A
  • VGA  -  1920×1080, 1280×1024, 1280×720, 1024×768
  • Display Split   - 16CH/13CH/10CH/9CH/8CH/6CH/4CH/1CH
  • Digital Zoom   - YES
  • OSD    Camera Title, Time, Recording, Motion Detection, Event Alarm

Recording

  • Video Compression  -  H265/H264/H265+/H264+
  • Resolution-12MP(4000*3000),8MP(3840×2160),6MP(3072*2048),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536),1080P(1920×1080),1280×1024,960P(1280×960),720P(1280×720),960H(960×480)D1(720×576/720×480)
  • Record Rate    PAL: 12MP@10CHx25fps,4K@16CHx25fps,5MP@16CH×25fps,4MP@16CHx25fps,3MP@16CH×25fps,1080P@16CH×25fps, 960P@16CH×25fps,720P@16CH×25fps, D1@16CH×25fps
  • NTSC: 12MP@10CHx30fps,4K@16CHx30fps,5MP@16CH×30fp,4MP@16CH×30fp,3MP@16CH×30fps,1080P@16CH×30fp,960P@16CH×30fp, 720P@16CH×30fp,D1@16CH×30fp
  • Record Mode -  Manual\Timer\Motion Detection\Smart Event

Playback & Backup

  • Local Sync Playback  -  1CH 12MP@30fps,1CH 8MP@30fps,2CH 5MP@30fps,4CH 4MP@30fps,7CH 1080P@30fps,16CH 720P@30fps,16CH D1@30fps
  • Decode Capability   - 1080P(1920×1080)@210fps
  • Remote Sync Playback  -  YES
  • Search Mode  -  ALL, Timing Video, Motion Detection, Tag  search,Smart Event,Pictrue,Log
  • Playback Functions  -  Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio
  • Backup Mode  -  USB Device/Network

Network

  • Interface -   1 RJ45(10M/100M/1000M self-adaptive Ethernet Interface)
  • Incoming Bandwidth  -  128Mbps
  • Outgoing Bandwidth  -  80Mbps
  • Network Functions  -  IPv4/IPv6/TCP/IP, HTTP,HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE
  • Onvif  -  Profile S, Profile T
  • Web Browser  -  Edge,IE8-11, Google Chrome , Firefox ,Safari
  • CMS Software  -  Support  Windows 7/ Windows 8/Windows 10/Windows 11/MAC OS
  • Cloud Support  -  Yes
  • Smart Phone -   iPhone,  Android
  • POE -   8 x Independent 100Mbps POE Network Interfaces(Output Power AT mode 30W per Interface, AF mode 15W per Interface), 45/78 line order, Total Power Output 72W,  Support Plug and Play, Support network cable extended mode Max. 200M
  • WIFI  -  N/A

Storage

  • Interface Type  -  1 SATA Hard Disk Interface (3.5″ SATA)
  • Capacity  -  Up to 10TB capacity
  • eSATA  -  N/A

General

  • Language  UI  -  Simplified Chinese, Traditional Chinese, English, Polski, Czech, Russian, Arabic, German, French, Portuguese, Spanish, Italian, Hungarian, Korean, Dutch, Greek, Janpanese, Ukrainian, Kazakh
  • USB Interface    2 USB 2.0 Interfaces
  • RS485  -  N/A
  • Power consumption  -  DC48V/1.87A  ≤ 10W (Without Hard Disk)
  • Working Environment  -  -10℃～50℃, 10%～90%(humidity)
  • Product Dimension(W×D×H) - 260*230*43(mm)
  • Net Weight  -  1.01kg(without HDD)
  • Gross Weight  -  1.75kg(without HDD)
