LTS CMHD7352-28 HD-TVI 5MP 2.8mm Platinum Starlight Security Camera


Sorry, this product has been discontinued.

LTS CMHD7352-28 HD-TVI 5MP Platinum Starlight 2.8mm IR LED 65ft Security Camera

Brand: LTS
MPN: CMHD7352-28
Condition: New

High Definition Dome 5MP HD-TVI Camera
2.8mm Fixed Lens
0.008 Lux@F1.2
2 Matrix IR 2.0 LED up to 65ft
UTC Control to OSD Menu
IK10 Vandal-Proof Dome
3-Axis Easy Installation
Smart IR
DC 12V
*Must be used with HD-TVI 4.0 DVR

Image Sensor: 1/2 .7 "CMOS
Signal System: NTSC/PAL
Effective Pixels: 2560(H)*1944(V)
Min. Illumination: 0.008 Lux , 0 Lux with IR
Shutter Speed: 1/30 (1/25)s to 1/50,000 s
Lens: 2.8mm , Angle of View: 91°
Day & Night: ICR
Synchronization: Internal
Video Frame Rate: 2560 x 1944@20fps
HD Video Output: 1 HD-TVI Output
S/N Ratio: More than 62dB
AGC: Support
D/N Mode: Auto/ Color/BW
White Balance: ATW/MWB
BLC: Support
Function: Brightness,Sharpness,Digital noise reduction,Mirror, Smart IR
Working Temperature/Humidity: -40 °F ~ 140 °F (-40 °C ~ 60 °C)
Humidity 90% or less (non-condensing)
Power Supply: DC 12V
Power Consumption: Max. 3W
Impact Protection: IK10
Weather Proof Ratings: IP67
IR Range: Up to 65ft (20m)
Impact Protection: IK10
Dimensions: 4.4 ”×3.3” (111.0×82.5 mm)
Weight: 0.8lb(350g)
