Klipsch PSM-800-T Full-Range 8” Indoor/Outdoor 70V/100V/8Ohm Surface Mount Loudspeaker - White

Availability:
Low stock
SKU KLIP-PSM-800-T-WHITE

Klipsch PSM-800-T Full-Range 8” Indoor/Outdoor 70V/100V/8Ohm Surface Mount Loudspeaker - White

The Klipsch PSM-800-T is a versatile 8” indoor/outdoor professional surface mount loudspeaker designed for high efficiency and low distortion. Featuring the patented Tractrix® Hyperfold Port™, it delivers powerful bass with minimal space, enhanced airflow, and reduced port noise. Ideal for commercial environments, it is IPX6 rated for water resistance and includes a multi-tap transformer for 70/100 volt installations, with an 8-ohm bypass option. The speaker boasts a 1” titanium compression driver for high-clarity sound, set screws on the grille for secure fitting, and a phoenix connector for easy installation, ensuring wide coverage and consistent audio performance.

  • More bass, less space with the all-new Tractrix® Hyperfold Port™
  • 1” Titanium Compression Driver for effortless, high-clarity detail
  • IPX6 Rated for even the most challenging commercial environments
  • Multi-tap transformer for 70 or 100 volt installations, includes bypass position
  • Set screws on grille
  • Phoenix Connector for simplified installation
  • Paintable, rust-proof aluminum grille
  • 5 Year Manufacturers Warranty

Docs/Instruction Links

Specifications:

  • Frequency Response: 52Hz-20kHz ± 4dB, 44Hz -10dB
  • Power Handling: 100 watts (21V) 50Hz-10kHz (400 watts peak)
  • Calculated Max Continuous Output: 109dB
  • Sensitivity: 92dB
  • Coverage: 100° ± 20° (1kHz-20kHz)
  • Directivity Index: 7dB ± 1.5dB (800Hz-20kHz)
  • Nominal Impedance: 8 ohms, 4.2 ohms at 150Hz minimum
  • Acoustic Crossover: 2kHz
  • Transducers: 8” woofer, 1” titanium compression driver on a K-1200M horn/tweeter bridge
  • Enclosure Material: All-weather ABS plastic, paintable
  • IP Rating: IPX6
  • Enclosure Tuning: Vented via 3 folded Tractrix ports
  • Input Connectors: 4-pin euro block
  • Transformer Taps:
    • 70V: 100W, 50W, 25W, 12.5W
    • 100V: 100W, 50W, 25W
    • Bypass position: 8 ohms nominal
  • Dimensions [with bracket]: 15.5” (394mm) x 12” (305mm) x 9.31” (237mm) [11.12” (283mm)]
  • Weight: 15.75 lbs (7.15kg)
