Earthquake Sound PHS3500.1 Full Range Monoblock 3500W Class-D Car Audio Amplifier

Availability:
Out of stock
SKU EAR-PHS3500-1
Sold out

Earthquake Sound PHS3500.1 Full Range Monoblock 3500W Class-D Car Audio Amplifier

Built for the audio nuts out there that eat, sleep, and breathe SPL, the Shredder makes its return for your chassis flexing and window shattering enjoyment. Earthquake Sound is proud to bring to you the all-new PowerHouse Shredder Series. These full-range digital high current monoblock amplifiers are weapons of mass destruction that are well equipped for the most demanding of mobile audio addicts and bassheads. From the heavy-duty heat sinks to the massive terminals, PHS amps deliver brute power to drive the biggest speakers all while staying ice cold. With so much power at your disposal you’d think you’d need a license to own one.

Specification:

  • Channels: 1
  • Class: Digital Class D
  • Power Output @ 1Ω: 3500 WRMS @ 1% THD
  • Power Output @ 2Ω: 2000 WRMS @ 1% THD
  • Power Output @ 4Ω: 1200 WRMS @ 1% THD
  • Frequency Response: 15Hz–20kHz
  • High Pass Filter: 15Hz–80Hz
  • Low Pass Filter: 80Hz–20kHz
  • Bass Boost Range: 35Hz–70Hz
  • Bass Boost Level: 0–12dB
  • Signal-to-Noise Ratio: 90dB
  • Efficiency: 99%
  • Gain Min/Max: 5V–0.2V
  • Output Noise: 16mV
  • Full Rated Power Current Draw: 235A Gain At Max
  • Fuse Rating: 1Ω 200A / 2Ω 150A / 4Ω 100A
  • Minimum Wire Gauge Size: 1Ω 4–2 Gauge / 2Ω 2 Gauge / 4Ω 1 Gauge
  • Dimensions (H x W x D): 2.58″ (65mm) x 8.30″ (211mm) x 8.99″ (288mm)
  • Weight: 5.80 lbs (2.63 kgs)
