Small and powerful amplifier with power output of 4 x 70 Watts RMS, and in mono bridge-connection
It puts out all of 2 x 140 Watts
A good sounding amplifier for both amateurs and professionals
Built-in/switchable low pass and high pass filters
Damping factor >250
Signal to noise ratio, A-weighted: 110 dB
THD at 5W, 1 kHz. <0,02%
Built-in protection circuits shut down the amplifier in the event of overloads
Hi level input with Auto start
Use it for a front system and a subwoofer
Number of channels: 4
Amplifier class: AB
Output power in 2 ohm: 4 x 70 Watt
Output power in 4 ohm: 4 x 50 Watt
Mono bridge mode 4 ohm: 2 x 140 Watt
Damping factor: >250
S/N ratio, A-weighted: >110 dB
Frequency range: 10 Hz - 50 kHz
Input sensitivity: 1 - 4 Volt
Input impedance: 6 kohm
Input impedance, high level: 45 ohm
High level input with auto start: Yes
Remote bass level control: No
Low level output: No
Remote phase shift control: No
Filters channel A & B: HP 50 - 500 Hz, LP 50 - 500 Hz
Filters channel C & D: HP 50 - 500 Hz, LP 50 - 500 Hz
Power consumption (idle): 0.5 A
Power consumption (max): 40 A
Rec. power cable: 16 sq mm (5 AWG)
Fuses: 2 x 20 A
Dimensions (W x D x H): 129mm x 250mm x 51mm (5.07" x 9.85" x 2")
Weight: 1.8 kg
