DoorBird A1103 IP Video Indoor Station 7″ Touchscreen Monitor WiFi & PoE Smart Home Intercom Display - White

DoorBird A1103 IP Video Indoor Station 7″ Touchscreen Monitor WiFi & PoE Smart Home Intercom Display - White
Availability:
Low stock
SKU DOB-A1103

DoorBird A1103 IP Video Indoor Station – 7″ Touchscreen Monitor, WiFi & PoE, Smart Home Intercom Display - White

Meet the next evolution of indoor communication. The DoorBird A1103 brings a refined, modern interface to your smart home or building, combining a crisp 7” touchscreen with crystal-clear HD audio for effortless, reliable interaction at the door. Designed in Germany and built for real-world use, it delivers seamless control over doors, gates, lifts and more—right from a sleek, intuitive display.

With WiFi and PoE connectivity, SIP integration, and full smart home compatibility, the A1103 fits naturally into both residential and commercial environments. Add in room-to-room communication, visitor history with cloud recording, and a configurable LED status bar, and you’ve got more than an indoor station—you’ve got a central control point for access and awareness.

  • WiFi / LAN connection (PoE capable)
  • 7“ True IPS Touch Display
  • 2-way HD Audio, up to 102 dB
  • Room to room communication
  • SIP support
  • Home and building automation control
  • 2 freely configurable bistable switching relays

Docs/Instruction Links

Specifications

  • Material Polycarbonate, glass
  • Available in white
  • Mounting type Surface-mounted, table stand sold separately
  • Power supply 15 - 48 V DC (min. 15 W) or Power over
  • Ethernet (PoE 802.3af Mode-A)
  • Weight 510 g

Connectors

  • • RJ45, for LAN/PoE
  • • Digital input (0 V, 0 A (NO)) #1,e.g. for storey-call button
  • • Digital input (0 V, 0 A (NO)) #2,e.g. for second storey-call button
  • • Bistable latching relay #1,max. 24 V DC / AC, 1 A,
  • e.g. for electric door opener orelevator
  • • Bistable latching relay # 2,max. 24 V DC / AC, 1 A,e.g. for electric door opener or elevator
  • • 15 - 48 V DC input (+, -), max. 15 W

Power consumptions

  • max. 10 W

Approvals

  • CE RED (EMC,RF,Health, Safety), IEC/EN 62368,
  • FCC, IC, Reach 250, RoHs 2.0, California 65,
  • WEEE
  • Dimensions 146 x 185 x 26,04 mm (H x W x D)
  • 5.75 x 7.28 x 0.72 in (H x W x D)

Operating conditions

  • 0 to +55°C / 32 to 131°F
  • Humidity 0 % to 85 % (non condensing)

CURRENT SYSTEM REQUIREMENTS

  • Mobile device: Newest iOS on
  • iPhone/iPad, newest Android on
  • Smartphone/Tablet
  • Internet: High-Speed Landline Broadband
  • Internet connection, DSL, cable or fiber optic,
  • no socks or proxy server
  • Network: Ethernet Network, with DHCP
  • Supported door stations -  Any DoorBird IP Video Door Station
  • Dimensions 7“ True Color LCD
  • Touch Yes, capacitive
  • Resolution 1024 x 600 px
  • IPS Yes

AUDIO

  • Audio components Speaker and microphone, echo and
  • noise cancellation (AEC, ANR)
  • Audio streaming Two-way

NETWORK

  • Ethernet PoE IEEE 802.3at, 10/100 Base-T
  • WiFi 802.11 b/g/n 2.4 GHz
